Thông Số Kỹ Thuật:
| Display panel type | Gen 2 IPS (Gen 2 technology, also called AH-IPS, enables lower power consumption) LED backlit |
| Display size (diagonal) | 58.42 cm (màn hình 23 in) |
| Viewable image area (diagonal) | 58.42 cm (23 in) widescreen |
| Micro-edge bezel | Yes, 3 sided |
| Panel hardness | 3H |
| Panel active area (W x H) | 50.90 x 28.63 cm (20.04 x 11.27 in) |
| Aspect ratio | 16:9 |
| Viewing angle (typical CR > 10) | Up to 178° horizontal (10:1 minimum contrast ratio) Up to 178° vertical (10:1 minimum contrast ratio) |
| Brightness | 250 cd/m2 |
| Static contrast ratio | 1,000:1 static (typical) |
| Dynamic contrast ratio | 10,000,000:1 (typical) |
| Response times | 5 ms gray to gray NOTE: Default is 14.0 ms and can be adjusted to as low as 5.4 ms in the display menu. See user guide for more information. |
| Flicker free | Yes |
| Pixel pitch | 0.2652 mm |
| Pixels Per Inch (PPI) | 96 |
| Default color temperature | sRGB D65 (6500 K) |
| Backlight lamp life | 30,000 hours minimum (to half brightness) |
| Panel bit depth | 8-bit (6-bit with A-FRC) 16.7 million colors |
| Anti-glare panel | Yes Haze 25% |
| Low Blue Light Capable | Yes User selectable in OSD Menu |
NOTE: Actual performance varies.
User controls
| Specification | Description |
| Buttons or switches | Menu/OK Minus button/Down/Color Control Plus button/Up/Viewing Mode Menu Exit/Back/Next Active Input Power |
| User-assignable function buttons | Yes, 10 |
| Languages | 10 (English, Spanish, German, French, Italian, Dutch, Portuguese, Japanese, Simplified Chinese, and Traditional Chinese) |
| On-screen Display (OSD) user controls | Brightness, Contrast, Color Control, Input Control, Image Control, Power Control, Menu Control, Management, Language, Information, and Exit |
Signal interface/performance
| Specification | Description |
| Native resolution/timing | 1920 x 1200 at 60 Hz (preferred) NOTE: Supports up to 75 Hz refresh for some video modes. The video card of the connected PC must be capable of supporting 75 Hz. |
| Maximum resolution | 1920 x 1200 at 60 Hz |
| Recommended resolution | 1920 x 1200 at 60 Hz |
| Preset graphic modes/Supported resolutions | 640 x 480 at 60 Hz and 75 Hz 720 x 400 at 70 Hz 800 x 600 at 60 Hz and 75 Hz 1024 x 768 at 60 Hz and 75 Hz 1280 x 720 at 60 Hz 1280 x 800 at 60 Hz 1280 x 1024 at 60 Hz and 75 Hz 1440 x 900 at 60 Hz 1600 x 900 at 60 Hz 1680 x 1050 at 60 Hz 1920 x 1080 at 60 Hz and 75 Hz |
| Pixel clock | 180 MHz (maximum) |
| Vertical scan range | 50 - 75 Hz |
| Horizontal scan range | 30 - 84 kHz |
Color management
| Specification | Description |
| sRGB | > 94% sRGB |
| Factory color calibrated | Yes |
| Factory calibration accuracy | White point maximum 3.0 ∆E 2000 Grayscale average (255 levels) maximum 3.0 ∆E 2000 Gamma target tolerance (2.2 for sRGB, 2.4 for BT.709) +/- 0.1 X-Rite ColorChecker average maximum 3.0 ∆E 2000 |
Video/other inputs
| Specification | Description |
| Connector types | (1) DisplayPort (DP) 1.2 (1) HDMI 1.4 (1) VGA HDCP support for DisplayPort and HDMI |
| USB ports | (3) USB 3.0 (2) Downstream and (1) Upstream |
Ergonomics
| Specification | Description |
| Color of monitor bezel and stand | Space Silver head Black Pearl chin Die-Cast aluminum base with Black Pearl paint |
| Plug and play | Yes |
| Tilt range | -5° to +22° vertical |
| Swivel | +/- 45 |
| Pivot | Yes Pivot (clockwise and counter clockwise) Detent at 0° |
| Height adjustment range | Yes 0 to 150 mm |
| 4-Way comfort adjust | Adjustable height, tilt, swivel and pivot |
| Integrated quick release | LCD monitor mounting solution Quickly and securely attaches an LCD monitor to a variety of stands, brackets, arms or wall mounts NOTE: The HP Quick Release has been designed to support a maximum of up to 10.9 kg (24 lb) for all devices mounted. Because mounting surfaces vary widely and the final mounting method and configuration might vary, mounting fasteners are not supplied (other than the VESA-compliant screws). HP recommends that you consult with a qualified engineering, architectural or construction professional to determine the appropriate type and quantity of mounting fasteners required for your application and to ensure that your mounting solution is properly installed to support applied loads. |
| Cable management | Effortless routing of cables through the cable management tunnel at the base of the column |
| VESA mounting | Yes, 100 mm |
| Security lock-ready | Yes |
| Detachable base | Yes |
Power
| Specification | Description |
| Power supply | Internal |
| Input power | 100 - 240 VAC 50/60 Hz |
| Maximum power | 32 W |
| Typical power | 18 W |
| Energy saving/standby mode | 0.5 W |
| Power cable length | 1.9 m (6.23 ft) |
Physical specifications
| Specification | Description |
| Dimensions (W × D × H) | Unpacked with stand(highest setting) 50.93 x 20.50 x 45.72 cm (20.5 x 8.07 x 18.0 in) Packaged 60.20 x 39.12 x 26.42 cm (23.7 x 15.4 x 10.4 in) Head only 54.61 x 4.32 x 31.17 cm (21.5 x 1.7 x 12.27 in) Base area footprint 23.70 x 1.09 x 20.50 cm (9.33 x 0.43 x 8.07 in) |
| Weight | Unpacked 5.9 kg (13.00 lb) Packed 8.4 kg (18.52 lb) Head only 3.3 kg (7.23 lb) |
What's in the box?
| Specification | Description |
| Monitor and accessories | HP Z23n G2 23-inch Display AC power cord, 1.9 m (6.23 ft) DisplayPort (DP) cable, 2.0 m (6.56 ft) USB 3.0, b-a cable 1.8 m (5.91) |
| Documentation | CD (includes user guide, warranty, and drivers) HP Display Assistant software NOTE: HP Display Assistant is a software utility that enables theft deterrence and allows monitor adjustment, color calibration, and security/asset management using the Display Data Channel Command Interface (DDC/CI) protocol of the connected PC or workstation. |
Environmental
| Specification | Description |
| Temperature | Operating 5° to 35° C (41° to 95° F) Non-operating -20° to 60° C (-4° to 140° F) |
| Humidity | Operating 20% to 80% non-condensing Non-operating 5% to 95% (38.7° C maximum wet-bulb) |
| Altitude | Operating 0 to 5,000 m (0 to 16,400 ft) Non-operating 0 to 12,192 m (0 to 40,000 ft) |
| Arsenic-free display glass | Yes |
| White LED backlights | Yes |
| Mercury-free display backlighting | Yes |
| Low Halogen | Yes |
