Total Power | 650 Watts | ||
80 PLUS Efficiency | Bronze | ||
AC Input Rating | 100 - 240V | ||
Input Current | 10A-5A | ||
Frequency | 47 - 63Hz | ||
PSU Form Factor | ATX | ||
Modular | No | ||
Dimensions | 150mm (W) x 86mm (H) x 125mm (L) | ||
Weight | 1.9 | ||
Fan | Sleeve Bearing | 120mm | |
MTBF hours | 100,000 hours | ||
Multi-GPU ready | No | ||
Zero RPM Mode | No | ||
iCUE Compatibility | No | ||
Connector | Type | Connectors (Cable x Connectors Per Cable) | Total Length |
ATX Cable 24 Pin (20+4) | 1 x 1 | 550mm (± 10mm) | |
EPS/ATX12V 8 Pin (4+4) Cable | 2 x 1 | 600mm (± 10mm) | |
PCIe 8 Pin (6+2) Cable | 1 x 2 | 670mm (± 10mm) | |
SATA Cable (3 SATA) | 2 x 3 | 690mm (± 10mm) | |
SATA-PATA-PATA-FDD | 1 x 4 | 810mm (± 10mm) | |
Protections Technology | OVP (Over Voltage) UVP (Under Voltage) SCP (Short Circuit) OTP (Over Temp) OPP (Over Power) | ||
Warranty | 3 years | ||
Package contents | CV Series Power Supply AC power cord Cable ties Mounting screws Warranty Documentation |
